PHP20N06T,127

$0.59

Description：NEXPERIA PHP20N06T - 20.3A, 55V,
Series：TrenchMOS™
Mfr：Nexperia USA Inc.
Package：Bulk

SKU:f9989f9cd7d8 Category: Single FETs, MOSFETs Brand: Nexperia USA Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PHP20N06T,127 is listed in the Single FETs, MOSFETs range at ChipApex. The manufacturer field lists Nexperia USA Inc.. Its product description is NEXPERIA PHP20N06T - 20.3A, 55V,. Review the specifications below when checking this part for your BOM.

Single FETs, MOSFETs specifications for PHP20N06T,127

Description：NEXPERIA PHP20N06T - 20.3A, 55V,
Series：TrenchMOS™
Mfr：Nexperia USA Inc.
Package：Bulk
FET Type：N-Channel
Technology：MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)：55 V
Current - Continuous Drain (Id) @ 25°C：20.3A (Tc)
Drive Voltage (Max Rds On, Min Rds On)：10V
Rds On (Max) @ Id, Vgs：75mOhm @ 10A, 10V
Vgs(th) (Max) @ Id：4V @ 1mA
Gate Charge (Qg) (Max) @ Vgs：11 nC @ 10 V
Vgs (Max)：±20V
Input Capacitance (Ciss) (Max) @ Vds：483 pF @ 25 V
FET Feature：-
Power Dissipation (Max)：62W (Tc)
Operating Temperature：-55°C ~ 175°C (TJ)
Grade：-
Qualification：-
Mounting Type：Through Hole
Supplier Device Package：TO-220AB
Package / Case：TO-220-3

Single FETs, MOSFETs datasheet and documents for PHP20N06T,127

PHP20N06T,127

Single FETs, MOSFETs Overview

The PHP20N06T,127 is an N-channel TrenchMOS standard level FET in a TO-220AB package. It features a drain-source voltage of 55 V and a continuous drain current of 20.3 A at 25 °C. Total power dissipation reaches 62 W at 25 °C mounting base temperature. The device exhibits low on-state resistance, specified as 75 mΩ max at 25 °C and 150 mΩ max at 175 °C (VGS=10V, ID=10A). Gate charge is typically 11 nC. Junction temperature ranges from -55 °C to +175 °C.

Single FETs, MOSFETs Feature Summary

Low conduction losses due to low on-state resistance
Suitable for high frequency applications due to fast switching characteristics

Single FETs, MOSFETs Applications

DC-to-DC convertors
Switched-mode power supplies

Single FETs, MOSFETs Procurement Notes

Verify the active status and availability directly with Nexperia or authorized distributors before design finalization. Confirm that the TO-220AB plastic single-ended package with heatsink mounting aligns with thermal requirements. Ensure compliance with the stated absolute maximum ratings to prevent permanent damage during operation.

Single FETs, MOSFETs Selection Notes

Select this component for designs requiring robust N-channel switching with moderate voltage ratings. Verify thermal management capabilities against the 62 W dissipation limit and junction-to-mounting base thermal resistance. Ensure gate drive voltages remain within the ±20 V limit to maintain reliability and performance standards.

Single FETs, MOSFETs Part Context

This part belongs to the Nexperia TrenchMOS standard level FET series. It utilizes silicon technology for enhanced switching performance. The product is designed for computing, communications, consumer, and industrial applications only, excluding medical or life support equipment.
