PIC32MX530F128L-V/PT

$4.06

Description：IC MCU 32BIT 128KB FLASH 100TQFP
Series：PIC® 32MX
Mfr：Microchip Technology
Package：Tray
Core Processor：MIPS32® M4K™

SKU:b34b39ed50d3 Category: Microcontrollers Brand: Microchip Technology

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PIC32MX530F128L-V/PT is listed in the Microcontrollers range at ChipApex. The manufacturer field lists Microchip Technology. Its product description is IC MCU 32BIT 128KB FLASH 100TQFP. Review the specifications below when checking this part for your BOM.

Microcontrollers specifications for PIC32MX530F128L-V/PT

Description：IC MCU 32BIT 128KB FLASH 100TQFP
Series：PIC® 32MX
Mfr：Microchip Technology
Package：Tray
Core Processor：MIPS32® M4K™
Core Size：32-Bit Single-Core
Speed：40MHz
Connectivity：CANbus, I2C, IrDA, LINbus, PMP, SPI, UART/USART, USB OTG
Peripherals：Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Number of I/O：81
Program Memory Size：128KB (128K x 8)
Program Memory Type：FLASH
EEPROM Size：-
RAM Size：16K x 8
Voltage - Supply (Vcc/Vdd)：2.3V ~ 3.6V
Data Converters：A/D 48x10b
Oscillator Type：Internal
Operating Temperature：-40°C ~ 105°C (TA)
Mounting Type：Surface Mount
Supplier Device Package：100-TQFP (12x12)
Package / Case：100-TQFP
Grade：Automotive
Qualification：AEC-Q100

Microcontrollers datasheet and documents for PIC32MX530F128L-V/PT

PIC32MX530F128L-V/PT

Microcontrollers Overview

The PIC32MX530F128L-V/PT is a 32-bit microcontroller from the PIC32MX family, featuring a MIPS32 M4K core operating at up to 50 MHz. It integrates 128 KB of Flash program memory and 16 KB of SRAM data memory within a 100-pin TQFP package. The device supports an operating voltage range of 2.3V to 3.6V and includes USB 2.0-compliant Full-speed OTG, CAN 2.0B, I2S audio interfaces, and a Charge Time Measurement Unit (CTMU).

Microcontrollers Feature Summary

Integrates a MIPS32 M4K core with MIPS16e mode for code size optimization.
Includes a USB 2.0-compliant Full-speed On-The-Go controller and CAN 2.0B interface.
Features a Charge Time Measurement Unit (CTMU) supporting capacitive touch sensing.
Provides flexible Peripheral Pin Select (PPS) for function remapping.

Microcontrollers Applications

Audio applications utilizing I2S and fractional clock generation capabilities.
Human-Machine Interface (HMI) designs requiring capacitive touch sensing via CTMU.
Industrial control systems using CAN bus communication.
USB-enabled embedded devices requiring On-The-Go connectivity.

Microcontrollers Procurement Notes

Verify the specific suffix 'V' against official Microchip documentation to confirm it denotes the extended industrial temperature range (-40°C to +105°C). Ensure the 'L' designation corresponds to the 100-pin TQFP package configuration. Confirm that the '-I' or '-V' speed grade aligns with the required 50 MHz operational frequency for your application environment.

Microcontrollers Selection Notes

Select this component when a balance of processing power and peripheral integration is required. The 128 KB Flash and 16 KB RAM support moderate firmware complexity. The inclusion of both USB OTG and CAN makes it suitable for connected devices. Verify that the 100-pin TQFP footprint fits the target PCB layout constraints.

Microcontrollers Part Context

This part belongs to the PIC32MX1XX/2XX/5XX 64/100-PIN Family. It shares architectural similarities with other members like the PIC32MX570F512L but offers lower memory capacity. The family is designed for general-purpose applications with advanced analog and communication features.
