PIC32MZ2064DAL176T-V/2J

Microcontrollers Overview

The PIC32MZ2064DAL176T-V/2J is a 32-bit microcontroller from the PIC32MZ Graphics (DA) family, featuring a MIPS32 microAptiv core operating at 200 MHz. It integrates 2 MB of Flash memory and 640 KB of SRAM within a 176-pin LQFP package. The device includes an internal DDR2 controller supporting up to 32 MB of external SDRAM, alongside a 3-layer graphics controller with a 2D GPU. Key peripherals include USB 2.0 HS OTG, Ethernet MAC, dual CAN modules, six UARTs, and multiple high-speed communication interfaces.

Microcontrollers Feature Summary

• Integrated 3-layer graphics controller with a high-performance 2D GPU for display rendering
• Internal DDR2 SDRAM controller interface for expanded memory capacity
• Hardware crypto engine with RNG supporting AES, 3DES, SHA, MD5, and HMAC
• Six 12-bit ADC modules capable of 18 Msps conversion rates

Microcontrollers Applications

• High-performance graphical user interfaces
• Industrial control systems requiring safety certification
• Audio processing applications utilizing I2S interfaces
• Networked embedded devices with Ethernet connectivity

Microcontrollers Procurement Notes

Verify the specific suffix 'V/2J' against the manufacturer's current datasheet revision DS60001565C to confirm operational temperature range and package specifications. Ensure compatibility with required power supply voltages (VDDIO and VDDCORE) during design validation. Cross-reference pinout details for the 176-LQFP package to validate PCB layout constraints.

Microcontrollers Selection Notes

Select this component when designs require significant on-chip memory combined with dedicated graphics acceleration capabilities. The inclusion of an internal DDR2 controller distinguishes it from variants lacking this feature. Evaluate the MIPS32 microAptiv core performance against application processing demands and verify that the 176-pin package fits the physical enclosure constraints.

Microcontrollers Part Context

This device belongs to the PIC32MZ Graphics DA family, designed for applications demanding high throughput and multimedia processing. It shares architectural similarities with other members of the series but is distinguished by its specific memory configuration and integrated DDR2 controller support. The family targets complex embedded systems requiring robust peripheral integration.
