PKE8416JAPI

PKE8416JAPI is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Flex Power Modules. Its product description is 9-75VIN; 43.2-52.8VOUT; 40W; ISO. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for PKE8416JAPI

• Description：9-75VIN; 43.2-52.8VOUT; 40W; ISO
• Series：PKE 8000A
• Mfr：Flex Power Modules
• Package：Tray
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：9V
• Voltage - Input (Max)：75V
• Voltage - Output 1：48V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：830mA
• Power (Watts)：40 W
• Voltage - Isolation：2.25 kV
• Applications：ITE (Commercial)
• Features：Adjustable Output, Remote On/Off
• Operating Temperature：-40°C ~ 115°C (With Derating)
• Efficiency：91%
• Mounting Type：Through Hole
• Package / Case：6-DIP Module
• Size / Dimension：2.00" L x 1.00" W x 0.47" H (50.8mm x 25.4mm x 11.9mm)
• Supplier Device Package：-
• Control Features：Enable, Active Low
• Approval Agency：cURus, UL
• Standard Number：62368-1
• Grade：-
• Qualification：-
