PKV3313PI is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Flex Power Modules. Its product description is DC DC CONVERTER 12V 3W. Review the specifications below when checking this part for your BOM.
DC DC Converters specifications for PKV3313PI
- Description：DC DC CONVERTER 12V 3W
- Series：PKV (3W)
- Mfr：Flex Power Modules
- Package：Tray
- Type：Isolated Module
- Number of Outputs：1
- Voltage - Input (Min)：9V
- Voltage - Input (Max)：36V
- Voltage - Output 1：12V
- Voltage - Output 2：-
- Voltage - Output 3：-
- Voltage - Output 4：-
- Current - Output (Max)：250mA
- Power (Watts)：3 W
- Voltage - Isolation：1.5 kV
- Applications：ITE (Commercial)
- Features：-
- Operating Temperature：-40°C ~ 95°C (With Derating)
- Efficiency：82%
- Mounting Type：Through Hole
- Package / Case：24-DIP Module, 10 Leads
- Size / Dimension：1.25" L x 0.80" W x 0.42" H (31.8mm x 20.3mm x 10.7mm)
- Supplier Device Package：-
- Control Features：-
- Approval Agency：CB, CSA, IEC, TUV, UL
- Standard Number：62368-1
- Grade：-
- Qualification：-
DC DC Converters datasheet and documents for PKV3313PI
