PL8207

$6.91

Description：CMC 3.3A 2LN SMD
Series：-
Mfr：iNRCORE, LLC
Package：Tube

SKU:2c7a479b18d7 Category: Common Mode Chokes Brand: iNRCORE, LLC

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PL8207 is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists iNRCORE, LLC. Its product description is CMC 3.3A 2LN SMD. Review the specifications below when checking this part for your BOM.

Common Mode Chokes specifications for PL8207

Description：CMC 3.3A 2LN SMD
Series：-
Mfr：iNRCORE, LLC
Package：Tube
Filter Type：Power Line
Number of Lines：2
Current Rating (Max)：3.3A
DC Resistance (DCR) (Max)：60mOhm
Voltage Rating - DC：-
Voltage Rating - AC：-
Operating Temperature：-55°C ~ 130°C
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Surface Mount
Size / Dimension：0.770" L x 0.670" W (19.56mm x 17.02mm)
Height (Max)：0.390" (9.91mm)
Package / Case：Horizontal, 4 PC Pad
Inductance @ Frequency：-
Impedance @ Frequency：-

Common Mode Chokes datasheet and documents for PL8207

PL8207

Common Mode Chokes Overview

The PL8207 is a two-line surface mount common mode choke manufactured by iNRCORE, LLC. It features a maximum current rating of 3.3A and a DC resistance (DCR) of 60mOhm. The component operates within a temperature range of -55°C to +130°C. Its physical dimensions are 19.56mm in length, 17.02mm in width, and 9.91mm in height.

Common Mode Chokes Feature Summary

Surface mount construction for automated assembly
Two-line configuration for common mode noise filtering
High thermal stability across extended temperature ranges

Common Mode Chokes Applications

Aerospace systems
Military electronics
Industrial power line filtering

Common Mode Chokes Procurement Notes

Verify RoHS compliance status as sources indicate non-compliance. Confirm specific datasheet revisions with the manufacturer. Ensure supply chain channels are authorized to guarantee component authenticity and traceability for critical aerospace or military deployments.

Common Mode Chokes Selection Notes

Select this component when high-temperature operation up to 130°C is required. The 3.3A rating suits moderate current applications. Verify footprint compatibility with the 19.56mm x 17.02mm package constraints during PCB layout design.

Common Mode Chokes Part Context

This part belongs to the iNRCORE inductor and choke portfolio. It serves as a signal integrity solution for differential lines. The product distinguishes itself through robust thermal handling capabilities suitable for demanding environments.
