PLT10HH450180PNL

$9.22

Description：CMC 18A 2LN 45 OHM SMD AEC-Q200
Series：PLT10H
Mfr：Murata Electronics
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:48c2f9f4d10a Category: Common Mode Chokes Brand: Murata Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PLT10HH450180PNL is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists Murata Electronics. Its product description is CMC 18A 2LN 45 OHM SMD AEC-Q200. Review the specifications below when checking this part for your BOM.

Common Mode Chokes specifications for PLT10HH450180PNL

Description：CMC 18A 2LN 45 OHM SMD AEC-Q200
Series：PLT10H
Mfr：Murata Electronics
Package：Tape & Reel (TR),Cut Tape (CT)
Filter Type：Power Line
Number of Lines：2
Current Rating (Max)：18A
DC Resistance (DCR) (Max)：1.8mOhm
Voltage Rating - DC：300V
Voltage Rating - AC：-
Operating Temperature：-55°C ~ 125°C
Ratings：AEC-Q200
Approval Agency：-
Features：-
Mounting Type：Surface Mount
Size / Dimension：0.508" L x 0.358" W (12.90mm x 9.10mm)
Height (Max)：0.370" (9.40mm)
Package / Case：Vertical, 4 PC Pad
Inductance @ Frequency：-
Impedance @ Frequency：45 Ohms @ 10 MHz

Common Mode Chokes datasheet and documents for PLT10HH450180PNL

PLT10HH450180PNL

Common Mode Chokes Overview

The Murata PLT10HH450180PNL is a two-line common mode choke designed for surface mount installation. It operates within a temperature range of -55°C to +85°C and meets AEC-Q200 automotive standards. Key electrical parameters include an inductance of 0.8µH, a maximum DC resistance of 1300µΩ (1.8mΩ), and an impedance of 45 Ohms at 10 MHz. The component supports a DC current rating of 18A, making it suitable for high-current power line applications.

Common Mode Chokes Feature Summary

Supports large currents up to 18A for robust power line filtering
Automotive qualified with AEC-Q200 compliance
Surface mount design for automated assembly integration

Common Mode Chokes Applications

Automotive power line filtering
High-current circuit noise suppression
EMI mitigation in vehicle electronics

Common Mode Chokes Procurement Notes

Verify the complete part number including suffixes such as 'PNL' to ensure correct packaging configuration. Confirm that the specified impedance and current ratings align with the target application's electrical requirements before procurement. Cross-reference datasheet revisions to ensure compatibility with existing designs.

Common Mode Chokes Selection Notes

Select this component when high current handling capacity near 18A is required alongside effective common mode noise reduction. The low DC resistance minimizes power loss in power lines. Ensure the operating environment stays within the -55°C to +85°C range and that surface mount footprint constraints are met.

Common Mode Chokes Part Context

This component belongs to the Murata PLT10HH series of common mode chokes. The series is engineered for automotive and industrial applications requiring reliable EMI suppression in high-current environments. The specific model integrates compact surface mount packaging with high thermal stability.

Common Mode Chokes Replacement Considerations

Check for direct substitutes within the PLT10HH series or other Murata CMCs with matching 18A rating and similar impedance characteristics. Verify package dimensions and pinout compatibility if considering alternatives from other manufacturers.
