PM2741NLT

$1.96

Description：CMC 1.1A 4LN SMD AEC-Q200
Series：PM27XXXXNLT
Mfr：Pulse Electronics
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:83134e52adc8 Category: Common Mode Chokes Brand: Pulse Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PM2741NLT is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists Pulse Electronics. Its product description is CMC 1.1A 4LN SMD AEC-Q200. Review the specifications below when checking this part for your BOM.

Common Mode Chokes specifications for PM2741NLT

Description：CMC 1.1A 4LN SMD AEC-Q200
Series：PM27XXXXNLT
Mfr：Pulse Electronics
Package：Tape & Reel (TR),Cut Tape (CT)
Filter Type：Power Line
Number of Lines：4
Current Rating (Max)：1.1A
DC Resistance (DCR) (Max)：30mOhm
Voltage Rating - DC：-
Voltage Rating - AC：-
Operating Temperature：-40°C ~ 125°C
Ratings：AEC-Q200
Approval Agency：-
Features：-
Mounting Type：Surface Mount
Size / Dimension：0.360" L x 0.230" W (9.14mm x 5.84mm)
Height (Max)：0.150" (3.80mm)
Package / Case：Vertical, 8 Flat Lead
Inductance @ Frequency：-
Impedance @ Frequency：-

Common Mode Chokes datasheet and documents for PM2741NLT

PM2741NLT

Common Mode Chokes Overview

The PM2741NLT is a single-channel surface-mount common mode filter from the Pulse Electronics SLIC/Shasta series. It features an inductance of 94 µH and a maximum DC resistance of 30 mΩ. The component provides 450 Ω impedance at its self-resonant frequency of 15 MHz. Designed for automotive applications, it holds AEC-Q200 qualification and operates within a temperature range of -40°C to +125°C. Physical dimensions are 9.1 mm x 8.9 mm x 3.8 mm.

Common Mode Chokes Feature Summary

AEC-Q200 qualified for automotive reliability standards
Surface-mount construction for automated PCB assembly
Single-channel design for specific line filtering

Common Mode Chokes Applications

Subscriber Line Interface Circuit (SLIC) protection
Automotive communication bus filtering
Telecommunications equipment signal conditioning

Common Mode Chokes Procurement Notes

Verify the exact part number against official Pulse Electronics documentation to confirm specifications. Ensure compatibility with your board layout regarding the specified SMD footprint. Confirm that the AEC-Q200 qualification meets your specific automotive grade requirements before finalizing procurement decisions.

Common Mode Chokes Selection Notes

Select this component when designing circuits requiring common mode noise suppression for subscriber lines or automotive buses. Consider the 94 µH inductance and 15 MHz self-resonant frequency for appropriate frequency targeting. Verify that the physical size fits within the available PCB area and that the thermal performance suits the operating environment.

Common Mode Chokes Part Context

This component belongs to the SLIC/Shasta series by Pulse Electronics, specialized for telecommunications and automotive applications. It serves as a passive electromagnetic interference filter, distinct from power inductors or general-purpose chokes. The series focuses on compact form factors suitable for dense electronic assemblies.
