Product Detailed Parameters
- Description：CMC 5.6MH 2.25A 2LN THROUGH HOLE
- Series：PMCE
- Mfr：Premier Magnetics
- Package：Bulk
- Filter Type：Power Line
- Number of Lines：2
- Current Rating (Max)：2.25A
- DC Resistance (DCR) (Max)：80mOhm
- Voltage Rating - DC：-
- Voltage Rating - AC：3750V (3.75kV)
- Operating Temperature：-40°C ~ 80°C
- Ratings：-
- Approval Agency：-
- Features：-
- Mounting Type：Through Hole
- Size / Dimension：0.826" L x 0.750" W (21.00mm x 19.05mm)
- Height (Max)：1.063" (27.00mm)
- Package / Case：-
- Inductance @ Frequency：5.6 mH @ 1 kHz
- Impedance @ Frequency：-
Download product information
Overview
The PMCE-0056 is a two-line common mode choke manufactured by Premier Magnetics, designed for EMI/RFI suppression in power line applications. It features through-hole mounting and offers an inductance of 5.6 mH at 1 kHz. The component supports a maximum current rating of 2.25A with a maximum DC resistance (DCR) of 80mOhm. It has an AC voltage rating of 3750V (3.75kV). Physical dimensions are 0.826 inches in length, 0.750 inches in width, and a maximum height of 1.063 inches.
Feature Summary
- Provides EMI/RFI filtering for power lines
- Supports high isolation voltage requirements
- Designed for through-hole PCB mounting
Applications
- Industrial equipment power filtering
- Power supply input stages
- Signal conditioning circuits requiring noise suppression
Procurement Notes
Verify the specific datasheet version from Premier Magnetics to confirm mechanical tolerances and insulation ratings. Ensure the selected component meets the required UL/CSA recognition standards for your target market. Cross-reference the pinout and physical footprint with your PCB design files before finalizing procurement orders.
Selection Notes
Select this component when a 5.6 mH common mode inductance is required for 2.25A applications. Consider the 3750V AC rating for high-isolation environments. Evaluate the through-hole package constraints against available board space. Compare DCR specifications against thermal management requirements in the final assembly.
Part Context
Premier Magnetics specializes in magnetic components for power conversion and signal conditioning. The PMCE series represents their standard line of EMI/RFI common mode line filters. These products are engineered for reliability and manufacturability, supporting various industrial and commercial electronic systems requiring effective noise reduction.
Replacement Considerations
Consult official Premier Magnetics documentation for direct substitutes. Verify that any alternative part matches the 5.6 mH inductance, 2.25A current rating, and 3750V AC voltage rating. Ensure physical dimensions and mounting type compatibility before substitution.
