PPC123M010FG2SAA

Product Detailed Parameters

• Description：CAP ALUM POLY 12000UF 20% 10V
• Series：PPC
• Mfr：Cornell Dubilier Knowles
• Package：Box
• Type：Polymer
• Capacitance：12000 µF
• Tolerance：±20%
• Voltage - Rated：10 V
• ESR (Equivalent Series Resistance)：6mOhm
• Lifetime @ Temp.：2000 Hrs @ 125°C
• Operating Temperature：-55°C ~ 125°C
• Ratings：-
• Applications：General Purpose
• Ripple Current @ High Frequency：18 A @ 20 kHz
• Lead Spacing：-
• Size / Dimension：6.250" L x 5.000" W (158.75mm x 127.00mm)
• Height - Seated (Max)：0.039" (1.00mm)
• Surface Mount Land Size：-
• Mounting Type：Chassis Mount
• Package / Case：FlatPack, Tabbed
• Ripple Current @ Low Frequency：16 A @ 120 Hz
• Features：-
