PREC012DAAN-RC

Headers, Male Pins Overview

The PREC012DAAN-RC is a vertical, breakaway header connector manufactured by Sullins Connector Solutions. It features 24 positions arranged in two rows with a 0.100 inch (2.54mm) pitch. Designed for through-hole board-to-board or cable applications, the component utilizes phosphor bronze contacts with tin plating. The housing is constructed from polybutylene terephthalate (PBT), rated UL94 V-0, and operates within a temperature range of -65°C to 125°C. The connector supports a current rating of 3A and includes push-pull fastening.

Headers, Male Pins Feature Summary

• Vertical breakaway design allows for easy separation into individual pin strips.
• Push-pull fastening mechanism secures mating connections without screws.
• Tin-plated phosphor bronze contacts ensure reliable signal transmission.
• UL94 V-0 rated PBT insulation provides flame resistance and thermal stability.

Headers, Male Pins Applications

• Board-to-board interconnections in industrial control systems
• Cable-to-board assemblies in consumer electronics
• Signal routing in telecommunications equipment

Headers, Male Pins Procurement Notes

Verify that the specific ordering suffix matches the required contact length and housing height specifications. Confirm RoHS compliance status and REACH registration details prior to procurement. Ensure the selected variant aligns with the intended through-hole mounting process and peak soldering temperature limits defined in the official datasheet.

Headers, Male Pins Selection Notes

Select this component when a vertical, breakaway header is required for low-current signal applications. The 2.54mm pitch suits standard PCB layouts. Consider the push-pull feature for secure mating. Verify that the 3A current rating meets circuit requirements. Ensure the operating temperature range covers the environmental conditions of the final assembly.

Headers, Male Pins Part Context

This part belongs to the PREC01 series of rectangular headers from Sullins Connector Solutions. The series offers various position counts and configurations for general-purpose interconnect needs. The breakaway design distinguishes it from fixed-length headers, providing flexibility in production line assembly and inventory management.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 24-position count, 2-row layout, 2.54mm pitch, and vertical orientation. Verify compatibility of the push-pull fastening mechanism and through-hole termination style. Inspect housing material and flammability ratings to ensure equivalent performance in the target application environment.
