PREC017DBAN-M71RC

Headers, Male Pins Overview

The PREC017DBAN-M71RC is a rectangular connector header from the Sullins Connector Solutions family, designed for through-hole right-angle mounting. It features an unshrouded configuration with male pin contacts and a dual-row arrangement providing 34 positions. The connector utilizes a 0.100-inch (2.54mm) pitch between pins and maintains a 0.100-inch row spacing. Contact surfaces are finished with gold plating to ensure reliable signal transmission. The unit is packaged in bulk and supports solder termination methods for secure PCB attachment.

Headers, Male Pins Feature Summary

• Dual-row unshrouded header design for high-density board-to-board or cable connections
• Gold-plated male pin contacts for enhanced conductivity and corrosion resistance
• Right-angle through-hole mounting orientation for space-efficient PCB layouts

Headers, Male Pins Applications

• Industrial control system interconnections
• Consumer electronics board assembly
• Telecommunications equipment signal routing

Headers, Male Pins Procurement Notes

Verify the specific part number against official manufacturer documentation to confirm current availability status. Check for any superseded revisions or alternative suffixes that may indicate minor manufacturing updates. Ensure compatibility with existing PCB footprint designs before procurement. Confirm RoHS compliance requirements match project specifications. Review datasheet drawings for precise mechanical dimensions to avoid assembly conflicts.

Headers, Male Pins Selection Notes

Select this component when a dual-row, right-angle header with 34 positions is required. The 2.54mm pitch ensures compatibility with standard ribbon cables and mating connectors. Gold plating is suitable for applications requiring stable electrical performance over time. Consider the unshrouded design if lateral alignment guides are provided by the mating interface. Evaluate thermal and current ratings against circuit load requirements.

Headers, Male Pins Part Context

This component belongs to the PREC series of rectangular headers manufactured by Sullins Connector Solutions. The series offers various position counts and row configurations to support diverse electronic assembly needs. The M71RC suffix typically denotes specific packaging and material characteristics within the product line. These headers are engineered for durability and consistent electrical connection in commercial and industrial environments.

Headers, Male Pins Replacement Considerations

PRPC017DBAN-M71RC serves as a direct functional substitute within the same manufacturer lineup, offering identical mechanical and electrical specifications. Cross-referencing with other distributors may reveal equivalent parts from different brands, but verify pin count, pitch, and mounting style carefully. Always validate dimensional tolerances and contact finish requirements before substituting.
