PRPC014DABN-RC

Headers, Male Pins Overview

PRPC014DABN-RC is a rectangular header connector from the PRPC series by Sullins Connector Solutions. It features a vertical, unshrouded design with 28 positions in a dual-row configuration. The pitch is 0.100 inches (2.54 mm), and it utilizes male pin contacts with gold plating for reliable signal transmission. Designed for through-hole mounting, this component supports a current rating of 3A per contact. The housing is black PBT material rated UL94 V-0, ensuring stability across an operating temperature range of -40°C to 105°C.

Headers, Male Pins Feature Summary

• Dual-row vertical header configuration for high-density board-to-board connections
• Gold-plated male pins ensure durable electrical performance and corrosion resistance
• Unshrouded breakaway design allows for flexible assembly and custom row separation

Headers, Male Pins Applications

• Industrial control systems requiring robust signal interconnects
• Consumer electronics utilizing standard 2.54mm pitch interfaces
• Test and measurement equipment needing reliable vertical headers

Headers, Male Pins Procurement Notes

Verify that the specific suffix 'RC' aligns with your environmental compliance requirements, as indicated in the part number. Confirm that the 28-position count matches your circuit design needs. Ensure the through-hole mounting style is compatible with your PCB fabrication process. Check that the 3A current rating per contact is sufficient for your application's power distribution. Validate the vertical orientation against your mechanical enclosure constraints.

Headers, Male Pins Selection Notes

Select this model when a dual-row, vertical header with 2.54mm pitch is required. The unshrouded design offers flexibility for custom spacing if rows are separated. Gold plating is suitable for low-signal applications where contact resistance must be minimized. The 3A rating supports moderate power loads. Consider the breakaway feature if single-row usage is anticipated later in the product lifecycle.

Headers, Male Pins Part Context

This component belongs to the PRPC series of rectangular connectors, which are characterized by their versatile header designs. The series includes various configurations for different mounting styles and position counts. PRPC014DABN-RC specifically addresses the need for a 28-position vertical interface. It complements other Sullins products like the PBC series, offering a specialized solution for dual-row applications within the broader rectangular connector family.

Headers, Male Pins Replacement Considerations

Compatible substitutes include PRPC014DAAN-RC and PRPC014SADN-RC. Verify that alternative parts maintain the same 28-position count and 2.54mm pitch. Ensure the replacement also features a vertical orientation and dual-row layout. Confirm that the contact finish and current ratings meet or exceed the original specifications.
