PRPN241PAEN

Headers, Male Pins Overview

The PRPN241PAEN is a single-row male pin header manufactured by Sullins Connector Solutions. It features 24 positions with a 2mm (0.079 inch) pitch. The connector utilizes brass contacts with gold flash termination and gold plating for mating surfaces. Constructed with Polybutylene Terephthalate insulation, it supports a dielectric voltage of 500VAC and an insulation resistance of 5 GΩ. The component measures 1.89 inches in length and 0.079 inches in width.

Headers, Male Pins Feature Summary

• Single-straight configuration designed for board-to-board or cable applications
• Gold-plated brass contacts ensure reliable electrical conductivity
• Polybutylene Terephthalate insulator provides structural stability

Headers, Male Pins Applications

• Board-to-board interconnections
• Cable-to-board connections
• General electronic circuit assembly

Headers, Male Pins Procurement Notes

Verify the specific part number against official manufacturer documentation to confirm current availability status. Ensure that the required contact finish and insulation material specifications align with project requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a single-row header with a 2mm pitch is required. Confirm that the 24-position count matches the design layout. Verify compatibility with mating connectors regarding contact gender and physical dimensions.

Headers, Male Pins Part Context

This part belongs to the PRPN series of male pin headers from Sullins Connector Solutions. The series offers various position counts and row configurations. This specific model represents a standard straight header variant within that product family.

Headers, Male Pins Replacement Considerations

Check for NRPN381PAEN-RC as a related series component, though position counts differ. Verify cross-compatibility with other 2mm pitch headers from different manufacturers based on mechanical footprint and electrical ratings.
