PRQ150W-Q48-S15-D

PRQ150W-Q48-S15-D is listed in the DC DC Converters range at ChipApex. The manufacturer field lists CUI Inc.. Its product description is DC DC CONVERTER 15V 150W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for PRQ150W-Q48-S15-D

• Description：DC DC CONVERTER 15V 150W
• Series：PRQ150W
• Mfr：CUI Inc.
• Package：Tray
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：18V
• Voltage - Input (Max)：75V
• Voltage - Output 1：15V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：10A
• Power (Watts)：150 W
• Voltage - Isolation：2.25 kV
• Applications：ITE (Commercial)
• Features：Adjustable Output, Remote On/Off, Remote Sense
• Operating Temperature：-40°C ~ 85°C (With Derating)
• Efficiency：89%
• Mounting Type：Through Hole
• Package / Case：Quarter Brick
• Size / Dimension：2.43" L x 1.58" W x 0.50" H (61.8mm x 40.2mm x 12.7mm)
• Supplier Device Package：Quarter Brick
• Control Features：-
• Approval Agency：CE
• Standard Number：62368-1
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for PRQ150W-Q48-S15-D
