PS2565L1-1Y-A

$1.21

Description：OPTOISOLATOR 5KV 1CH TRANS 4-DIP
Series：-
Mfr：Renesas Electronics Corporation
Package：Tube

SKU:275e87516e17 Category: Transistor, Photovoltaic Output Optoisolators Brand: Renesas Electronics Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：OPTOISOLATOR 5KV 1CH TRANS 4-DIP
Series：-
Mfr：Renesas Electronics Corporation
Package：Tube
Number of Channels：1
Voltage - Isolation：5000Vrms
Current Transfer Ratio (Min)：80% @ 5mA
Current Transfer Ratio (Max)：400% @ 5mA
Turn On / Turn Off Time (Typ)：-
Rise / Fall Time (Typ)：3µs, 5µs
Input Type：AC, DC
Output Type：Transistor
Voltage - Output (Max)：80V
Current - Output / Channel：50mA
Voltage - Forward (Vf) (Typ)：1.17V
Current - DC Forward (If) (Max)：80 mA
Vce Saturation (Max)：300mV
Operating Temperature：-55°C ~ 100°C
Mounting Type：Through Hole
Package / Case：4-DIP (0.400", 10.16mm)
Supplier Device Package：4-DIP
Grade：-
Qualification：-

Download product information

PS2565L1-1Y-A

Overview

The PS2565L1-1Y-A is a single-channel transistor output optocoupler manufactured by Renesas Electronics. It features an NPN phototransistor output and supports through-hole DIP-4 mounting. The device provides 5000 Vrms isolation voltage with a maximum collector-emitter voltage of 80 V and a maximum collector current of 50 mA. Key electrical parameters include a forward voltage of 1.17 V, a power dissipation of 150 mW, and switching times of 3 µs rise and 5 µs fall. It operates within a temperature range of -55°C to +100°C.

Feature Summary

Provides high-voltage isolation capability for signal transmission between circuits
Features AC input response characteristics suitable for various control applications
Utilizes NPN phototransistor output for reliable digital signal coupling

Applications

Telephone and FAX equipment interfaces
FA/OA (Factory Automation/Office Automation) equipment
Programmable logic controller (PLC) systems

Procurement Notes

Verify the specific suffix designation against official Renesas documentation to confirm package type and tape/reel specifications. Ensure compliance with RoHS3 standards and check for any recent product change notices regarding labeling or manufacturing site updates before finalizing procurement orders.

Selection Notes

Select this component when high isolation voltage and AC input response are required in a compact form factor. Consider the 80 V collector-emitter voltage rating and 50 mA output current capacity for driving subsequent stages. Verify that the DIP-4 through-hole package aligns with the target PCB layout requirements.

Part Context

This part belongs to the PS2565 series of multi-photocouplers designed for general-purpose isolation. The series includes variants with different packages and safety approvals. The PS2565L1-1Y-A specifically denotes a version optimized for AC input response with standard transistor output characteristics.
