PS2733-1-A

$3.10

Description：OPTOISOLTR 2.5KV 1CH DARL 4-SOP
Series：NEPOC
Mfr：Renesas Electronics Corporation
Package：Strip

SKU:57c91bc3b70c Category: Transistor, Photovoltaic Output Optoisolators Brand: Renesas Electronics Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：OPTOISOLTR 2.5KV 1CH DARL 4-SOP
Series：NEPOC
Mfr：Renesas Electronics Corporation
Package：Strip
Number of Channels：1
Voltage - Isolation：2500Vrms
Current Transfer Ratio (Min)：1500% @ 1mA
Current Transfer Ratio (Max)：-
Turn On / Turn Off Time (Typ)：-
Rise / Fall Time (Typ)：100µs, 100µs
Input Type：DC
Output Type：Darlington
Voltage - Output (Max)：350V
Current - Output / Channel：150mA
Voltage - Forward (Vf) (Typ)：1.15V
Current - DC Forward (If) (Max)：50 mA
Vce Saturation (Max)：1V
Operating Temperature：-55°C ~ 100°C
Mounting Type：Surface Mount
Package / Case：4-SMD, Gull Wing
Supplier Device Package：4-SOP
Grade：-
Qualification：-

Download product information

PS2733-1-A

Overview

The PS2733-1-A is a single-channel optoisolator manufactured by Renesas Electronics Corporation, featuring a Darlington transistor output. It provides an isolation voltage of 2500Vrms and supports a maximum output voltage of 350V. The device operates with a DC input type and has a typical forward voltage of 1.15V. Key electrical parameters include a maximum DC forward current of 50mA, a channel output current of 150mA, and a minimum current transfer ratio of 1500% at 1mA. The saturation voltage is rated at a maximum of 1V, with typical rise and fall times of 100µs each. It functions within a temperature range of -55°C to 100°C and is housed in a 4-SOP surface-mount package.

Feature Summary

High current transfer ratio capability for efficient signal transmission
Robust insulation performance suitable for demanding isolation applications
Wide operating temperature range for reliable industrial use

Applications

Industrial automation control systems
Power supply feedback loops
Solid-state relay drivers

Procurement Notes

Verify the specific suffix against official Renesas documentation to confirm exact packaging and tape-and-reel specifications. Ensure compatibility with existing PCB footprints and thermal management requirements before finalizing procurement orders.

Selection Notes

Select this component when high current drive capability via a Darlington output is required alongside strong galvanic isolation. Consider the 2500Vrms rating for safety-critical interfaces and verify that the 100µs switching speed meets the system timing constraints.

Part Context

This part belongs to the NEPOC series from Renesas, designed for general-purpose isolation tasks. It complements other devices in the portfolio by offering a balance between high gain and robust insulation in a compact surface-mount form factor.
