PSDH30120L1_T0_00001 is listed in the Single Diodes range at ChipApex. The manufacturer field lists Panjit International Inc.. Its product description is DIODE STD 1200V 30A TO247AD2. Review the specifications below when checking this part for your BOM.
Single Diodes specifications for PSDH30120L1_T0_00001
- Description：DIODE STD 1200V 30A TO247AD2
- Series：-
- Mfr：Panjit International Inc.
- Package：Tube
- Technology：Standard
- Voltage - DC Reverse (Vr) (Max)：1200 V
- Current - Average Rectified (Io)：30A
- Voltage - Forward (Vf) (Max) @ If：2.6 V @ 30 A
- Speed：Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr)：240 ns
- Current - Reverse Leakage @ Vr：250 µA @ 1200 V
- Capacitance @ Vr, F：-
- Mounting Type：Through Hole
- Package / Case：TO-247-2
- Supplier Device Package：TO-247AD-2
- Operating Temperature - Junction：-55°C ~ 150°C
- Grade：-
- Qualification：-
Single Diodes datasheet and documents for PSDH30120L1_T0_00001
Single Diodes FAQ
Is the PSDH30120L1_T0_00001 available in a datasheet?
No verified datasheet or technical specification document is currently available for this specific part number.
What are the electrical parameters of the PSDH30120L1_T0_00001?
Technical data such as voltage ratings, current limits, and package dimensions cannot be provided due to the absence of official documentation.
