PT7M6837ID3TBEX

Supervisors Overview

The PT7M6837ID3TBEX is a fixed-channel power supply support circuit manufactured by Diodes Incorporated. It operates within an extended temperature range of -40°C to +85°C and utilizes a TSSOP-4 package. The device provides a fixed reset threshold voltage of 1.228V with a detect voltage accuracy of ±1.5%. It features low power consumption, typically 7.5μA, and offers multiple timeout periods including 70μs, 1.5ms, 30ms, 210ms, and 1.68s. The output configuration supports push-pull or open-drain RESET signals.

Supervisors Feature Summary

• Factory-set reset threshold voltages for nominal supplies from 1.2V to 1.8V
• Low power consumption typical of 7.5μA
• Immune to short negative Vcc transients
• Adjustable threshold reset-in option available

Supervisors Applications

• Microprocessor supervisory circuits in digital systems
• Monitoring low-voltage power supplies
• Ensuring circuit reliability in embedded applications

Supervisors Procurement Notes

Verify the specific suffix ID3TBEX against official Diodes Incorporated documentation to confirm pinout and electrical characteristics. Ensure compatibility with system voltage requirements and thermal constraints before integration. Cross-reference datasheet revisions for any updates to timing parameters or package dimensions.

Supervisors Selection Notes

Select this component when a fixed reset threshold near 1.23V is required for low-voltage monitoring. Consider the available timeout options and output configurations to match system reset timing needs. Verify that the TSSOP-4 package fits the PCB layout constraints and that the operating temperature range meets environmental specifications.

Supervisors Part Context

This part belongs to the PT7M6832–6840 series of ultra-low voltage detectors. These devices are designed to monitor power supplies in microprocessor and digital systems, providing reliable reset signals without external components. The series eliminates adjustments for +1.2V to +1.8V powered circuits.

Supervisors Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material.
