PTC19SFEN

Headers, Male Pins Overview

PTC19SFEN is a single-row male header connector manufactured by Sullins Connector Solutions. It features 19 positions with a 0.100 inch (2.54mm) pitch. The connector utilizes through-hole termination and square post contact style. Contact finish is tin with a thickness of 100µin (2.54µm). The insulator is black thermoplastic material rated UL94 V-0. Mating length is 0.318 inches (8.08mm).

Headers, Male Pins Feature Summary

• Single-row unshrouded male header design for standard board-to-board or cable applications.
• Square post contact style ensures reliable mechanical retention during mating cycles.
• Through-hole solder termination provides secure PCB mounting stability.

Headers, Male Pins Applications

• General purpose electronic interconnects
• Low-power microcontroller unit interfaces
• Standard board-to-board connections

Headers, Male Pins Procurement Notes

Verify the specific tin plating thickness and insulation flammability rating against the official datasheet before integration. Confirm that the single-row configuration matches the target PCB footprint requirements. Ensure mating components are compatible with the 0.100 inch pitch specification to maintain proper electrical continuity.

Headers, Male Pins Selection Notes

Select this component when a single-row male header with through-hole termination is required. The 19-position count suits moderate density interconnect needs. The tin finish offers cost-effective conductivity suitable for non-corrosive environments. Verify compatibility with mating female connectors having appropriate contact lengths.

Headers, Male Pins Part Context

This part belongs to the PTC series of rectangular headers from Sullins Connector Solutions. The series specializes in standard pitch male pins designed for general industrial and commercial electronics. It represents a common form factor within the manufacturer's extensive portfolio of interconnect solutions.

Headers, Male Pins Replacement Considerations

Compatible mating products include S7042-ND, S7007-ND, S5640-ND, S5601-ND, S5484-ND, S5445-ND, S4539-ND, S4500-ND, S4383-ND, S4344-ND, S4109-ND, S4009-ND, and S4009-ND variants as listed in manufacturer documentation.
