PTC21SFBN

Headers, Male Pins Overview

The PTC21SFBN is a single-row male header connector manufactured by Sullins Connector Solutions. It features 21 positions with a 0.100 inch (2.54mm) pitch. The connector utilizes square post contacts with tin plating, rated at 100µin thickness. Designed for through-hole right-angle mounting, it supports solder termination. The housing is black polybutylene terephthalate (PBT), meeting UL94 V-0 flammability standards. Operating temperature ranges from -65°C to 125°C.

Headers, Male Pins Feature Summary

• Right-angle through-hole mounting configuration for space-efficient board layout
• Single-row unshrouded design with all positions loaded
• Tin-plated square post contacts for reliable signal transmission
• High-temperature resistant PBT insulation material

Headers, Male Pins Applications

• General-purpose electronic interconnects
• Board-to-board connections in industrial equipment
• Consumer electronics assembly
• Control panel wiring interfaces

Headers, Male Pins Procurement Notes

Verify the specific suffix 'FBN' against official Sullins documentation to confirm tin plating and right-angle orientation. Ensure compatibility with mating female headers of matching pitch and contact type. Confirm RoHS compliance status via current manufacturer certificates before integration into regulated projects.

Headers, Male Pins Selection Notes

Select this component when a right-angle male header is required for single-row applications. The 2.54mm pitch ensures broad compatibility with standard PCB footprints. Consider the tin finish for cost-effective solutions where gold plating is unnecessary. Verify mechanical clearance for the right-angle profile during enclosure design.

Headers, Male Pins Part Context

This part belongs to the PTC series of rectangular connectors from Sullins Connector Solutions. The series offers various configurations including straight and right-angle options. It is designed for general interconnect needs in commercial and industrial sectors. The manufacturer provides associated mating products for complete connector systems.

Headers, Male Pins Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source data. Consult official distributor cross-reference tools or manufacturer engineering support for verified alternatives.
