PTM2-5-S15-S

PTM2-5-S15-S is listed in the DC DC Converters range at ChipApex. The manufacturer field lists CUI Inc.. Its product description is DC-DC, ISOLATED, 2 W, 4.5~5.5 VD. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for PTM2-5-S15-S

• Description：DC-DC, ISOLATED, 2 W, 4.5~5.5 VD
• Series：PTM2-S (2W)
• Mfr：CUI Inc.
• Package：Tube
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：4.5V
• Voltage - Input (Max)：5.5V
• Voltage - Output 1：15V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：134mA
• Power (Watts)：2 W
• Voltage - Isolation：6 kV
• Applications：ITE (Commercial), Medical
• Features：-
• Operating Temperature：-40°C ~ 95°C (With Derating)
• Efficiency：84%
• Mounting Type：Through Hole
• Package / Case：7-SIP Module, 4 Leads
• Size / Dimension：0.78" L x 0.28" W x 0.45" H (19.7mm x 7.1mm x 11.5mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：CE, cURus, UKCA
• Standard Number：60601-1; 62368-1
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for PTM2-5-S15-S
