PUC2412D1B

PUC2412D1B is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Flex Power Modules. Its product description is DC DC CONVERTER +/-12V 1W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for PUC2412D1B

• Description：DC DC CONVERTER +/-12V 1W
• Series：PUC-1B (1W)
• Mfr：Flex Power Modules
• Package：Tube
• Type：Isolated Module
• Number of Outputs：2
• Voltage - Input (Min)：21.6V
• Voltage - Input (Max)：26.4V
• Voltage - Output 1：12V
• Voltage - Output 2：-12V
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：42mA, 42mA
• Power (Watts)：1 W
• Voltage - Isolation：6 kV
• Applications：ITE (Commercial)
• Features：Adjustable Output
• Operating Temperature：-40°C ~ 100°C (With Derating)
• Efficiency：80%
• Mounting Type：Through Hole
• Package / Case：5-SIP Module
• Size / Dimension：0.78" L x 0.28" W x 0.45" H (19.7mm x 7.1mm x 11.5mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：cURus, IEC, UL
• Standard Number：62368-1
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for PUC2412D1B
