PV60K4032T

Overview

The PV60K4032T is a surface mount varistor from Stackpole Electronics Inc, designed for surge protection. It features a maximum AC voltage rating of 60V and a maximum DC voltage rating of 85V. The component has a clamping current of 1.2kA and an energy absorption capacity of 29J. Its typical varistor voltage is 430V, with a maximum of 473V. The device operates within a temperature range of -40°C to 85°C and exhibits a capacitance of 160pF at 1kHz. It utilizes a 2-SMD J-lead package.

Feature Summary

• Plastic-encapsulated construction for surface mount integration
• Designed to protect electronic equipment against high voltage surges
• Single circuit configuration for transient voltage suppression

Applications

• Protection of electronic circuits against high voltage surges
• Transient voltage suppression in surface mount assemblies
• Circuit protection for low voltage AC/DC lines

Procurement Notes

Verify the specific datasheet version for the PV60K4032T to confirm exact electrical tolerances and mechanical dimensions prior to design finalization. Ensure that the selected component meets the required surge current and energy ratings for the target application environment. Cross-reference the manufacturer's latest documentation for any updates on material compliance or packaging specifications.

Selection Notes

Select this component when a surface mount varistor is required for low voltage surge protection applications. Consider the 60V AC and 85V DC ratings to ensure compatibility with the system's operating voltage. Evaluate the 29J energy rating and 1.2kA clamping current against expected transient events. The 160pF capacitance should be assessed for high-speed signal integrity requirements.

Part Context

The PV Series consists of surface mount plastic-encapsulated varistors manufactured by Stackpole Electronics Inc. These components are part of a broader line of MOVs intended for circuit protection. The PV60K4032T specifically addresses the need for compact, reliable surge suppression in modern electronic designs requiring surface mount technology.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source data.
