PYBE30-Q24-S15H

PYBE30-Q24-S15H is listed in the DC DC Converters range at ChipApex. The manufacturer field lists CUI Inc.. Its product description is DC-DC ISOLATED, 30 W, 9~36 VDC I. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for PYBE30-Q24-S15H

• Description：DC-DC ISOLATED, 30 W, 9~36 VDC I
• Series：PYBE30 (30W)
• Mfr：CUI Inc.
• Package：Tube
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：9V
• Voltage - Input (Max)：36V
• Voltage - Output 1：15V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：2A
• Power (Watts)：30 W
• Voltage - Isolation：1.5 kV
• Applications：ITE (Commercial)
• Features：Adjustable Output, Heat Sink, Remote On/Off
• Operating Temperature：-40°C ~ 80°C (With Derating)
• Efficiency：90%
• Mounting Type：Through Hole
• Package / Case：6-DIP Module
• Size / Dimension：2.02" L x 1.03" W x 0.65" H (51.4mm x 26.2mm x 16.5mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：cURus, UL
• Standard Number：60950-1; 62368-1

DC DC Converters datasheet and documents for PYBE30-Q24-S15H
