PYBJ6-D12-S15-OM

PYBJ6-D12-S15-OM is listed in the DC DC Converters range at ChipApex. The manufacturer field lists CUI Inc.. Its product description is DC DC CONVERTER 15V 6W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for PYBJ6-D12-S15-OM

• Description：DC DC CONVERTER 15V 6W
• Series：PYBJ6 (6W)
• Mfr：CUI Inc.
• Package：Tray
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：9V
• Voltage - Input (Max)：18V
• Voltage - Output 1：15V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：400mA
• Power (Watts)：6 W
• Voltage - Isolation：1.5 kV
• Applications：ITE (Commercial)
• Features：Remote On/Off, OCP, OVP, SCP
• Operating Temperature：-40°C ~ 85°C
• Efficiency：85%
• Mounting Type：Surface Mount
• Package / Case：6-SMD Module
• Size / Dimension：1.24" L x 0.71" W x 0.25" H (31.6mm x 18.1mm x 6.3mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：CB Scheme, IEC, UL
• Standard Number：62368-1

DC DC Converters datasheet and documents for PYBJ6-D12-S15-OM
