PZC14SBAN

Headers, Male Pins Overview

The PZC14SBAN is a single-row, unshrouded board connector header manufactured by Sullins Connector Solutions. It features 14 male pin positions with a 0.100-inch (2.54mm) mating pitch. Designed for through-hole right-angle mounting, the component utilizes phosphor bronze contacts with tin plating and polybutylene terephthalate (PBT) insulation rated UL94 V-0. The black insulator supports an operating temperature range of -65°C to 125°C and provides a current rating of 3A per contact.

Headers, Male Pins Feature Summary

• Unshrouded single-row design for flexible board-to-board or cable interconnection
• Right-angle through-hole termination for space-efficient PCB layout
• Tin-plated phosphor bronze contacts ensuring reliable conductivity
• High-temperature resistant PBT insulation material

Headers, Male Pins Applications

• Industrial control system circuit boards
• Consumer electronic device internal connections
• Commercial computing hardware interfaces
• Military and aerospace mission-critical applications

Headers, Male Pins Procurement Notes

Verify that the specific suffix 'BAN' corresponds to the required tin-plated finish and PBT insulation material rather than gold or other variants. Confirm the right-angle orientation matches the mechanical constraints of the target assembly. Ensure compliance with RoHS3 and REACH regulations as specified in the official manufacturer documentation before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when an unshrouded, single-row header is required for high-density routing. The 0.100-inch pitch accommodates standard wire gauges and ribbon cables. Consider the right-angle form factor for vertical mating needs. Validate that the 3A current rating and -65°C to 125°C temperature range meet the environmental and electrical demands of the specific application scenario.

Headers, Male Pins Part Context

This part belongs to the Sullins Connector Solutions header family, which specializes in edge cards and rectangular connectors for demanding environments. The PZC series represents standard through-hole solutions designed for durability. As a male pin header, it mates with female sockets or wires, forming a critical link in various electronic assemblies ranging from commercial to military grade systems.

Headers, Male Pins Replacement Considerations

Cross-reference with PEC14SBAN and PEC14SGBN for similar 14-position, 0.100-inch pitch headers. Verify that the unshrouded configuration and right-angle mounting type are compatible with the existing mechanical design before substituting.
