PZC15SAAN

Headers, Male Pins Overview

The PZC15SAAN is a vertical male header connector manufactured by Sullins Connector Solutions. It features a 15-position single row configuration with a 0.100-inch (2.54mm) mating pitch. Designed for through-hole termination, the contacts are constructed from phosphor bronze with a gold plating on the mating surface and tin plating on the tail. The housing is made of black polybutylene terephthalate (PBT) rated UL94 V-0. The connector supports a maximum current rating of 3A and operates within a temperature range of -65°C to 125°C.

Headers, Male Pins Feature Summary

• Vertical board-to-board or cable mounting style with breakaway design
• Gold-plated square contact terminals for reliable signal transmission
• Push-pull fastening mechanism for secure mating engagement
• RoHS compliant construction with UL94 V-0 flammability rating

Headers, Male Pins Applications

• Industrial control system interconnections
• Consumer electronics circuit board assembly
• Telecommunications equipment signal routing
• General-purpose electronic device power distribution

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the manufacturer's official catalog to ensure correct contact length and insulation height specifications. Confirm that the required quantity matches the standard packaging format provided by authorized distributors. Check for any recent lifecycle status updates, as availability may vary across supply channels. Ensure compliance with relevant environmental directives such as RoHS and REACH requirements for your target market.

Headers, Male Pins Selection Notes

Select this component when a vertical male header with a 2.54mm pitch is required for through-hole PCB assembly. The breakaway feature allows for customizing the number of positions per row during manufacturing. Consider the 3A current rating and 125°C operating temperature limit for thermal management. Verify that the housing color and material properties meet the aesthetic and mechanical constraints of the final enclosure design.

Headers, Male Pins Part Context

This part belongs to the PBC/PZC series of male headers from Sullins Connector Solutions. These connectors are designed for high-density applications requiring robust mechanical retention. The series offers various pin counts and row configurations to accommodate different circuit board layouts. The vertical orientation facilitates direct board stacking or cable attachment in compact spaces.
