PZC22SBBN

Headers, Male Pins Overview

PZC22SBBN is a board connector manufactured by Sullins Connector Solutions. It features 22 contacts arranged in a single row with male pin terminals. The connector utilizes a 0.100-inch (2.54mm) pitch and is designed for right-angle mounting on printed circuit boards. The housing is constructed from black thermoplastic insulator material, providing electrical isolation. Contact surfaces are finished with gold over nickel to ensure reliable conductivity and corrosion resistance. The termination method employs wire wrap terminals for secure attachment to the mating interface.

Headers, Male Pins Feature Summary

• Right-angle board connector design for space-efficient PCB integration
• Gold over nickel contact finish for enhanced durability and signal integrity
• Wire wrap terminal style ensuring secure mechanical and electrical connections
• Black thermoplastic insulator housing for robust environmental protection

Headers, Male Pins Applications

• Industrial control system interconnections
• Consumer electronics internal board-to-board linking
• Telecommunications equipment signal routing
• Automotive electronic module connections

Headers, Male Pins Procurement Notes

Verify the specific RoHS compliance status and lead time requirements directly with authorized distributors or the manufacturer before ordering. Confirm that the right-angle orientation and wire wrap termination style match the target PCB layout constraints. Ensure the supplier provides valid traceability documentation for quality assurance purposes.

Headers, Male Pins Selection Notes

Choose this component when a right-angle male header with wire wrap termination is required for a 22-position interface. The 0.100-inch pitch must align with existing board patterns. Consider the black insulator color for visual identification needs. Validate that the operating temperature range meets the application's thermal environment specifications.

Headers, Male Pins Part Context

This part belongs to the PXC series of board connectors from Sullins Connector Solutions. The series offers various configurations for different mounting angles and contact counts. The PZC22SBBN specifically addresses applications needing a right-angle profile with high-density connectivity in a compact form factor.
