PZC24DAAN

Headers, Male Pins Overview

The PZC24DAAN is a vertical header connector manufactured by Sullins Connector Solutions. It features 48 positions arranged in two rows of 24 contacts each, with a 0.100-inch (2.54mm) pitch. The connector utilizes male pins with gold contact finish and is designed for through-hole solder termination. Constructed with black insulating material, it accommodates standard PCB layouts requiring dual-row vertical interconnection.

Headers, Male Pins Feature Summary

• Vertical mounting orientation for direct PCB insertion
• Dual-row configuration providing 48 total signal paths
• Gold-plated male pin contacts for reliable conductivity
• Through-hole solder termination method

Headers, Male Pins Applications

• General electronic circuit board interconnections
• Industrial control system modules
• Commercial equipment backplanes
• Consumer electronics internal wiring

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm exact pin length, insulation material, and flange characteristics. Ensure the selected variant matches the required PCB hole pattern and mating height specifications. Confirm RoHS compliance status if environmental regulations apply to the assembly process.

Headers, Male Pins Selection Notes

Select this component when a vertical male header is required for dual-row applications. Compare against similar models like PBC24DAFN for straight configurations or different pitch requirements. Ensure the contact current rating and voltage withstand capabilities meet the system design constraints before finalizing the part number.

Headers, Male Pins Part Context

This part belongs to the rectangular headers family from Sullins Connector Solutions. It serves as a standard interconnect solution for connecting edgeboards or daughter cards to main systems. The series offers various termination styles and orientations to support diverse mechanical integration needs in electronic assemblies.
