Description：DIODE ZENER 13V 500MW SOD323HE
Series：-
Mfr：Panjit International Inc.
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:1e60fc83da10 Category: Single Zener Diodes Brand: Panjit International Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PZS5113BCH_R1_00001 is listed in the Single Zener Diodes range at ChipApex. The manufacturer field lists Panjit International Inc.. Its product description is DIODE ZENER 13V 500MW SOD323HE. Review the specifications below when checking this part for your BOM.

Single Zener Diodes specifications for PZS5113BCH_R1_00001

Description：DIODE ZENER 13V 500MW SOD323HE
Series：-
Mfr：Panjit International Inc.
Package：Tape & Reel (TR),Cut Tape (CT)
Voltage - Zener (Nom) (Vz)：13 V
Tolerance：±5%
Power - Max：500 mW
Impedance (Max) (Zzt)：-
Current - Reverse Leakage @ Vr：50 nA @ 9.8 V
Operating Temperature：-55°C ~ 150°C (TJ)
Mounting Type：Surface Mount
Package / Case：SC-90, SOD-323F
Voltage - Forward (Vf) (Max) @ If：-
Grade：-
Qualification：-

Single Zener Diodes datasheet and documents for PZS5113BCH_R1_00001

PZS5113BCH_R1_00001

Single Zener Diodes Overview

The PZS5113BCH_R1_00001 is a silicon Zener diode from the Panjit PZS51xxxBCH series, designed for surface-mount applications in the SOD-323HE package. It provides a nominal Zener voltage of 13 V with a tolerance range of 12.4 V to 13.7 V at a test current of 0.05 mA. The device supports a maximum power dissipation of 500 mW and operates within a junction temperature range of -55°C to +150°C. Maximum reverse leakage current is specified at 0.05 µA when tested at 9.8 V.

Single Zener Diodes Feature Summary

Planar die construction optimized for automated assembly processes
Lead-free composition compliant with EU RoHS 2.0 standards
Green molding compound formulation adhering to IEC 61249 specifications

Single Zener Diodes Applications

Voltage regulation circuits
Overvoltage protection
Reference voltage generation

Single Zener Diodes Procurement Notes

Verify the specific part number against official manufacturer documentation to confirm electrical tolerances and package dimensions. Ensure compatibility with automated pick-and-place equipment due to the SMD form factor. Confirm compliance requirements such as RoHS 2.0 and halogen-free status prior to integration into final assemblies.

Single Zener Diodes Selection Notes

Select this component for designs requiring precise voltage clamping in compact surface-mount layouts. Evaluate thermal resistance characteristics to ensure adequate heat dissipation under continuous operation. Consider the low leakage current specification for high-impedance circuit applications where minimal current draw is critical.

Single Zener Diodes Part Context

This component belongs to the PZS51xxxBCH series manufactured by Panjit International Inc., which covers a wide voltage range from 3.9 V to 43 V. All devices in this series share identical mechanical footprints and packaging configurations, differing primarily in their nominal Zener voltage ratings and corresponding marking codes.
