Q12-5

Q12-5 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists XP Power. Its product description is DC DC CONVERTER 1200V 500MW. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for Q12-5

• Description：DC DC CONVERTER 1200V 500MW
• Series：XP EMCO - Q (0.5W)
• Mfr：XP Power
• Package：Box
• Type：High Voltage - Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：0.7V
• Voltage - Input (Max)：5V
• Voltage - Output 1：1200V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：417µA
• Power (Watts)：500 mW
• Voltage - Isolation：500 V
• Applications：ITE (Commercial)
• Features：Proportional Output
• Operating Temperature：-25°C ~ 70°C
• Efficiency：-
• Mounting Type：Through Hole
• Package / Case：4-DIP Module
• Size / Dimension：0.50" L x 0.50" W x 0.50" H (12.7mm x 12.7mm x 12.7mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：62368-1
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for Q12-5
