QLS6B-FKW-CNSNSF043

LED Indication - Discrete Overview

The Cree LED QLS6B-FKW-CNSNSF043 is a high-power RGB side-view surface-mounted LED from the XLamp Pro9 series. It features a PLCC-6 package with independent configuration and a rectangular colorless lens measuring 0.90mm x 3.95mm. The component operates within a temperature range of -40°C to +85°C. Electrical specifications include forward voltages of 2.1V, 3V, and 3.1V for respective channels, with power ratings around 76-78mW. Luminous intensity reaches up to 1850 mcd. Wavelengths are specified at 624nm, 540nm, and 480nm.

LED Indication - Discrete Feature Summary

• Side-view surface-mount design minimizes background image obstruction for high visual impact
• Independent RGB channel configuration within a compact PLCC-6 package
• High luminous intensity output suitable for commercial lighting applications

LED Indication - Discrete Applications

• General indoor commercial lighting
• Outdoor commercial lighting
• Architectural accent illumination

LED Indication - Discrete Procurement Notes

Verify the specific datasheet version for the QLS6B-FKW-CNSNSF043 to confirm exact binning classifications and forward voltage tolerances. Ensure compatibility with thermal management requirements for the intended enclosure. Cross-reference official Cree LED documentation for precise reflow soldering profiles and moisture sensitivity levels before integration into production lines.

LED Indication - Discrete Selection Notes

Select this component when side-view visibility is critical for display clarity. The independent RGB configuration allows for precise color mixing without optical interference between channels. Consider the PLCC-6 footprint for standard SMD assembly processes. Evaluate the operating temperature range against environmental conditions to ensure long-term reliability in both indoor and outdoor settings.

LED Indication - Discrete Part Context

This part belongs to the XLamp Pro9 family of high-power LEDs designed for demanding commercial environments. The QLS6B variant specifically targets side-view applications where minimizing background obstruction enhances visual performance. It complements other RGB solutions by offering high intensity in a standardized surface-mount package suitable for automated manufacturing.

LED Indication - Discrete Replacement Considerations

Consult official Cree LED substitution guides for direct equivalents. Verify pinout compatibility and thermal characteristics when considering alternative RGB SMD packages. Ensure wavelength and intensity specifications match the original design intent to maintain color consistency.
