QLSP1306A

Overview

The QLSP1306A is an Amber LED from Quelighting Corp, packaged in a 0603 (1608 Metric) surface-mount format. It operates with a forward voltage of 2.1V and a current rating of 20mA. The component emits light at a wavelength of 605nm, classified as Discrete LED Indication. Designed for top-view application, it serves as a status indicator within electronic assemblies.

Feature Summary

• Top-view configuration for direct visibility
• Amber emission color at 605nm wavelength
• Standard 0603 surface-mount package

Applications

• Status indication in electronic circuits
• Power supply visual feedback
• Signal processing hardware indicators

Procurement Notes

Verify the specific datasheet for thermal derating curves and reverse voltage limits before integration. Confirm that the 20mA current rating aligns with the target circuit design to ensure longevity. Check packaging specifications for tape-and-reel compatibility if automated assembly is required. Ensure storage conditions meet manufacturer recommendations to prevent moisture sensitivity issues prior to soldering.

Selection Notes

Select this component when a compact Amber indicator is required for space-constrained designs. The 0603 footprint offers a balance between visibility and board real estate. Consider the 2.1V forward voltage drop when calculating series resistor values or driver requirements. Verify that the 605nm wavelength meets visibility standards for the intended environment.

Part Context

Quelighting Corp manufactures LEDs across SSL, UV, IR, and status indicator segments. Founded in 2010, the company focuses on optoelectronics for various market applications. The QLSP1306A represents their discrete indication product line, targeting general-purpose electronic signaling needs.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
