QPQ1904TR13

Overview

The QPQ1904TR13 is a band boost filter manufactured by Qorvo, designed for signal conditioning in the 5 GHz Wi-Fi UNII2c-3 frequency band. It operates with a center frequency of 5.6625 GHz and provides a bandwidth of 345 MHz. The device functions as a band-pass filter with an insertion loss of 2 dB. It utilizes surface mount technology (SMD/SMT) for board mounting and is supplied in a reel package format.

Feature Summary

• Optimized for boosting signals within the 5 GHz Wi-Fi UNII2c-3 band
• Designed as a band-pass filter to enhance specific frequency ranges
• Utilizes surface mount construction for integration into electronic assemblies

Applications

• Signal conditioning for 5 GHz Wi-Fi systems
• UNII2c-3 band filtering applications
• Wireless communication devices requiring band boost filters

Procurement Notes

Verify component authenticity through authorized Qorvo distributors or certified suppliers. Confirm that the part number matches QPQ1904TR13 exactly, including the suffix indicating reel packaging. Check datasheets for humidity sensitivity handling requirements during storage and assembly. Ensure compatibility with surface mount reflow processes specified in official documentation.

Selection Notes

Select this component when designing circuits for the 5 GHz Wi-Fi UNII2c-3 band. Consider its 2 dB insertion loss and 345 MHz bandwidth specifications against system requirements. Evaluate surface mount compatibility for PCB layout. Compare performance metrics with alternative band boost filters if specific frequency shifts are needed.

Part Context

This component belongs to Qorvo's signal conditioning portfolio, specifically categorized under RF filters. It is part of the QPQ1904 series, which includes various band boost filters for wireless applications. The product falls under the broader category of wireless and RF integrated circuits used in modern communication infrastructure.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Consult Qorvo engineering support or official replacement guides for validated alternatives.
