QTM750D-200.000MBE-T

$4.50

Description：XTAL OSC XO 200.0000 MHZ LVDS
Series：QTM750D
Mfr：QST
Package：Tape & Reel (TR)

SKU:2b927a9b2104 Category: Oscillators Brand: QST

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：XTAL OSC XO 200.0000 MHZ LVDS
Series：QTM750D
Mfr：QST
Package：Tape & Reel (TR)
Base Resonator：Crystal
Type：XO (Standard)
Frequency：200 MHz
Function：Enable/Disable
Output：LVDS
Voltage - Supply：3.3V
Frequency Stability：±50ppm
Absolute Pull Range (APR)：-
Operating Temperature：-40°C ~ 85°C
Spread Spectrum Bandwidth：-
Current - Supply (Max)：50mA
Ratings：-
Mounting Type：Surface Mount
Package / Case：6-SMD, No Lead
Size / Dimension：0.276" L x 0.197" W (7.00mm x 5.00mm)
Height - Seated (Max)：0.063" (1.60mm)
Supplier Device Package：-

Download product information

QTM750D-200.000MBE-T

Overview

The QTM750D-200.000MBE-T is a standard LVDS crystal oscillator manufactured by QST, operating at a frequency of 200 MHz with a 3.3V supply voltage. It features an enable/disable function and utilizes a 6-SMD, no-lead package measuring 7.00mm x 5.00mm x 1.50mm. The device supports operation within a temperature range of -40°C to 85°C.

Feature Summary

Supports LVDS output signal for high-speed digital applications
Includes hardware enable and disable control functionality
Utilizes surface-mount technology with a lead-free package design

Applications

High-speed data communication interfaces
Digital signal processing systems
Network equipment clock generation

Procurement Notes

Verify the specific suffix 'D' indicates LVDS output rather than CMOS when sourcing replacements. Confirm the 6-SMD footprint matches the target PCB layout. Ensure the 3.3V supply requirement aligns with the system power rails. Check manufacturer documentation for exact aging specifications and tolerance limits before final integration.

Selection Notes

Select this component for designs requiring precise 200 MHz timing with low-jitter LVDS signals. Consider the enable pin for power management strategies in battery-operated devices. Evaluate the thermal performance within the specified -40°C to 85°C range for environmental compliance. Compare package dimensions against available board space constraints.

Part Context

This part belongs to the QTM750 series of quartz oscillators from QST. The series offers various frequencies and output types, including CMOS and LVDS variants. The D suffix typically denotes the LVDS output configuration, distinguishing it from standard CMOS models in the same physical package family.
