R-78AA15-0.5SMD

R-78AA15-0.5SMD is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Recom Power. Its product description is DC DC CONVERTER 15V 8W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for R-78AA15-0.5SMD

• Description：DC DC CONVERTER 15V 8W
• Series：INNOLINE R-78AA-0.5
• Mfr：Recom Power
• Package：Tube
• Type：Linear Regulator Replacement
• Number of Outputs：1
• Voltage - Input (Min)：18V
• Voltage - Input (Max)：32V
• Voltage - Output 1：15V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：500mA
• Power (Watts)：8 W
• Voltage - Isolation：-
• Applications：ITE (Commercial)
• Features：Remote On/Off, OTP, SCP
• Operating Temperature：-40°C ~ 85°C
• Efficiency：97%
• Mounting Type：Surface Mount
• Package / Case：10-SMD Module
• Size / Dimension：0.60" L x 0.38" W x 0.35" H (15.2mm x 9.7mm x 8.8mm)
• Supplier Device Package：-
• Control Features：Enable, Active High
• Approval Agency：-
• Standard Number：-

DC DC Converters datasheet and documents for R-78AA15-0.5SMD
