R1191L028D-TR

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Overview

The R1191L028D-TR is a fixed-output low-dropout (LDO) linear voltage regulator manufactured by Nisshinbo Micro Devices. It provides a stable 2.8V output with a maximum current capacity of 300mA. The device supports an input voltage range up to 16V and features a typical power supply rejection ratio (PSRR) of 70dB at 1kHz. Key electrical characteristics include a quiescent current of 100µA, a line regulation of 0.02%/V, and a load regulation of 50mV. It operates within a temperature range of -40°C to +85°C and includes protection against over-temperature, reverse current, and short circuits.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Feature Summary

• Manual ECO mode shift capability for optimized power consumption
• Integrated reverse current protection mechanism
• Built-in thermal shutdown and short-circuit protection

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Applications

• Battery-powered portable electronic devices
• Embedded systems requiring stable low-noise power rails
• IoT modules and sensor nodes

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Procurement Notes

Verify the specific suffix 'D-TR' matches the required DFN1616-6 package and reel quantity. Confirm that the fixed 2.8V output aligns with system requirements. Ensure compatibility with the 16V maximum input limit. Check RoHS compliance status if restricted substances are a concern. Validate lead times as production schedules may vary.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Selection Notes

Select this component when a compact surface-mount LDO with reverse current protection is needed. The DFN1616-6 package suits space-constrained designs. Consider the 100µA quiescent current for battery life optimization. Verify that the 300mA output current meets peak load demands without exceeding thermal limits.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Part Context

This part belongs to the R1191x series of LDO regulators from Nisshinbo Micro Devices. The series is characterized by manual ECO mode shifting and robust protection features. It serves as a power management solution for applications requiring efficient voltage regulation in small form factors.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Replacement Considerations

Cross-reference with other R1191L variants offering different fixed output voltages but identical packages and pinouts. Ensure substitute parts maintain the same 300mA current rating and reverse current protection capabilities.
