R2D-1512/H-R

R2D-1512/H-R is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Recom Power. Its product description is DC DC CONVERTER +/-12V 2W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for R2D-1512/H-R

• Description：DC DC CONVERTER +/-12V 2W
• Series：ECONOLINE R2D (2W)
• Mfr：Recom Power
• Package：Tape & Reel (TR),Cut Tape (CT)
• Type：Isolated Module
• Number of Outputs：2
• Voltage - Input (Min)：13.5V
• Voltage - Input (Max)：16.5V
• Voltage - Output 1：12V
• Voltage - Output 2：-12V
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：83mA, 83mA
• Power (Watts)：2 W
• Voltage - Isolation：3 kV
• Applications：ITE (Commercial), Medical
• Features：SCP
• Operating Temperature：-40°C ~ 100°C
• Efficiency：83%
• Mounting Type：Surface Mount
• Package / Case：10-SMD Module, 6 Leads
• Size / Dimension：0.60" L x 0.42" W x 0.35" H (15.2mm x 10.7mm x 9.0mm)
• Supplier Device Package：-
• Approval Agency：-

DC DC Converters datasheet and documents for R2D-1512/H-R
