R413I2220DQ00M

R413I2220DQ00M is listed in the Film Capacitors range at ChipApex. The manufacturer field lists KEMET. Its product description is CAP FILM 0.022UF. Review the specifications below when checking this part for your BOM.

Film Capacitors specifications for R413I2220DQ00M

• Description：CAP FILM 0.022UF
• Series：R41
• Mfr：KEMET
• Package：Cut Tape (CT),Tray
• Capacitance：0.022 µF
• Tolerance：±20%
• Voltage Rating - AC：300V
• Voltage Rating - DC：1000V (1kV)
• Dielectric Material：Polypropylene (PP), Metallized
• Operating Temperature：-40°C ~ 110°C
• Mounting Type：Through Hole
• Package / Case：Radial
• Size / Dimension：0.709" L x 0.236" W (18.00mm x 6.00mm)
• Height - Seated (Max)：0.476" (12.10mm)
• Termination：PC Pins
• Lead Spacing：0.591" (15.00mm)
• Applications：Automotive; EMI, RFI Suppression
• Ratings：AEC-Q200, X1, Y2
• Features：-
• ESR (Equivalent Series Resistance)：-

Film Capacitors datasheet and documents for R413I2220DQ00M
