R570012000

$294.89

Description：IC RF SWITCH SPDT 3GHZ MODULE
Series：-
Mfr：Radiall USA, Inc.
Package：Bulk

SKU:46289e65ca4d Category: RF Switches Brand: Radiall USA, Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC RF SWITCH SPDT 3GHZ MODULE
Series：-
Mfr：Radiall USA, Inc.
Package：Bulk
Product Status：Active
RF Type：General Purpose
Topology：-
Circuit：SPDT
Frequency Range：0Hz ~ 3GHz
Isolation：75dB (min)
Insertion Loss：0.25dB (max)
Test Frequency：3GHz
Impedance：50Ohm
Voltage - Supply：10.2V ~ 13V
Operating Temperature：-40°C ~ 85°C
Mounting Type：-
Package / Case：Module
P1dB：-
IIP3：-
Features：-
Supplier Device Package：Module
Grade：-
Qualification：-

Download product information

R570012000

Overview

The R570012000 is a coaxial switch from the Ramses series manufactured by Radiall. It features an N-type connector interface and operates as a Single Pole Double Throw (SPDT) device with a maximum frequency of 3 GHz. The unit utilizes a failsafe mechanism powered by a 12 Vdc supply and employs pin terminals for connection.

Feature Summary

Failsafe operational design ensures defined state upon power loss
N-type connector interface for standard coaxial integration

Applications

RF signal routing in communication systems
Test and measurement equipment switching
Aerospace electronic subsystems

Procurement Notes

Verify current lifecycle status directly with the manufacturer, as availability information is not explicitly detailed in public listings. Confirm specific voltage requirements and terminal compatibility before ordering to ensure system integration. Check for any regional distribution restrictions that may apply to this component.

Selection Notes

Select this model when a 3 GHz SPDT switching solution with N-type connectors is required. Ensure the system provides a stable 12 Vdc supply for the failsafe operation. Compare against the R570013000 if a 28 Vdc operating voltage is necessary instead.

Part Context

This component belongs to the Ramses family of coaxial switches produced by Radiall. The series includes variants with different connector types, frequency ranges, and control voltages. The R570012000 specifically addresses applications requiring N-type interfaces and 12 Vdc control within the 3 GHz bandwidth.

Replacement Considerations

The R570013000 serves as a functional substitute within the same Ramses series, differing primarily in its requirement for a 28 Vdc power supply rather than 12 Vdc.
