R570013000

$294.89

Description：IC RF SWITCH SPDT 3GHZ MODULE
Series：-
Mfr：Radiall USA, Inc.
Package：Bulk

SKU:781004bb9c0f Category: RF Switches Brand: Radiall USA, Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC RF SWITCH SPDT 3GHZ MODULE
Series：-
Mfr：Radiall USA, Inc.
Package：Bulk
Product Status：Active
RF Type：General Purpose
Topology：-
Circuit：SPDT
Frequency Range：0Hz ~ 3GHz
Isolation：75dB (min)
Insertion Loss：0.25dB (max)
Test Frequency：3GHz
Impedance：50Ohm
Voltage - Supply：24V ~ 30V
Operating Temperature：-40°C ~ 85°C
Mounting Type：-
Package / Case：Module
P1dB：-
IIP3：-
Features：-
Supplier Device Package：Module
Grade：-
Qualification：-

Download product information

R570013000

Overview

The Radiall R570013000 is a Ramses series coaxial switch featuring an SPDT configuration with N-type connectors. It operates up to 3GHz and utilizes a failsafe latching mechanism powered by 28Vdc. The device employs pin terminals for connection and includes non-illuminated indicators. Designed for panel mounting, it ensures reliable signal routing in RF applications while maintaining impedance stability.

Feature Summary

Failsafe latching operation maintains state without continuous power
N-type connector interface for standard coaxial integration
Non-illuminated status indicators for position verification

Applications

RF signal routing in communication systems
Test and measurement equipment setups
Aerospace and defense electronic assemblies

Procurement Notes

Verify component availability directly with the manufacturer or authorized distributors, as stock levels may vary. Confirm RoHS compliance and specific datasheet revisions prior to ordering. Ensure that the 28Vdc coil voltage requirement aligns with system power supplies. Validate connector type compatibility with existing infrastructure before finalizing procurement decisions.

Selection Notes

Select this model when a fail-safe switching mechanism is required for N-type coaxial lines up to 3GHz. The 28Vdc latching drive suits systems with compatible control voltages. Consider the physical dimensions and panel mount requirements during mechanical design. Verify that the SPDT topology meets the specific signal path needs of the application.

Part Context

This component belongs to the Ramses family of coaxial switches from Radiall USA, Inc. The series offers various configurations including different frequencies and connector types. The R570013000 specifically addresses applications requiring reliable switching at lower microwave frequencies with robust mechanical locking capabilities.

Replacement Considerations

Consult official Radiall documentation for verified substitute part numbers within the Ramses series. Cross-reference specifications such as frequency range, connector type, and drive voltage to ensure functional equivalence. Do not assume interchangeability with other brands without detailed technical comparison.
