Product Detailed Parameters
- Description：IC RF SWITCH SPDT 3GHZ MODULE
- Series：-
- Mfr：Radiall USA, Inc.
- Package：Bulk
- Product Status：Active
- RF Type：General Purpose
- Topology：-
- Circuit：SPDT
- Frequency Range：0Hz ~ 3GHz
- Isolation：80dB (min)
- Insertion Loss：0.15dB (max)
- Test Frequency：3GHz
- Impedance：50Ohm
- Voltage - Supply：10.2V ~ 13V
- Operating Temperature：-40°C ~ 85°C
- Mounting Type：-
- Package / Case：Module, SMA Connectors
- P1dB：-
- IIP3：-
- Features：-
- Supplier Device Package：Module
- Grade：-
- Qualification：-
Download product information
Overview
The Radiall R570312000 is a coaxial switch from the Ramses series, configured as an SPDT (Single Pole Double Throw) unit. It utilizes N-type connectors and supports frequencies up to 3 GHz. The device operates with a failsafe mechanism powered by 12 Vdc TTL signals. Electrical connections are established via pin terminals. This component is designed for high-reliability RF signal routing in demanding environments.
Feature Summary
- SPDT configuration for single-pole double-throw switching
- N-type connector interface for robust connection
- Failsafe operation ensuring defined state upon power loss
- 12 Vdc TTL control signal compatibility
Applications
- Aerospace defense systems
- Telecommunications infrastructure
- Test and measurement equipment
Procurement Notes
Verify current availability directly with the manufacturer or authorized distributors, as stock status may vary. Confirm RoHS compliance and REACH SVHC details prior to integration. Ensure the 12 Vdc TTL control requirement aligns with system design specifications. Check for any specific environmental certifications required for the target application sector.
Selection Notes
Select this model when an SPDT switching topology with N-type interfaces is required. The 3 GHz frequency range suits many UHF and lower microwave applications. The failsafe feature is critical for safety-critical aerospace or defense circuits. Verify that the 12 Vdc control voltage matches the available system logic levels before procurement.
Part Context
This part belongs to the Ramses series of coaxial switches manufactured by Radiall USA, Inc. The series is known for reliability in harsh environments. Other variants in the family may offer different connector types such as SMA or different pole configurations like SP6T, but this specific number denotes the N-type SPDT version.
Replacement Considerations
Consult official Radiall documentation for direct cross-reference substitutes. Alternative models within the Ramses series may provide compatible form factors but require verification of connector type and control voltage specifications.
