R570312100

$235.70

Description：IC RF SWITCH SPDT 3GHZ MODULE
Series：-
Mfr：Radiall USA, Inc.
Package：Bulk

SKU:4fa78855f163 Category: RF Switches Brand: Radiall USA, Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC RF SWITCH SPDT 3GHZ MODULE
Series：-
Mfr：Radiall USA, Inc.
Package：Bulk
Product Status：Active
RF Type：General Purpose
Topology：-
Circuit：SPDT
Frequency Range：0Hz ~ 3GHz
Isolation：80dB
Insertion Loss：0.2dB
Test Frequency：3GHz
Impedance：50Ohm
Voltage - Supply：10.2V ~ 13V
Operating Temperature：-40°C ~ 85°C
Mounting Type：-
Package / Case：Module, SMA Connectors
P1dB：-
IIP3：-
Features：-
Supplier Device Package：Module
Grade：-
Qualification：-

Download product information

R570312100

Overview

The Radiall R570312100 is a coaxial switch from the Ramses series, configured as an SPDT unit with SMA connectors. It operates up to 3 GHz and features a failsafe mechanism. The device utilizes 12VDC TTL control signals for actuation. Internal diodes are integrated for protection, and connection terminals are provided via solder pins.
