R570313000

$160.85

Description：IC RF SWITCH SPDT 3GHZ MODULE
Series：-
Mfr：Radiall USA, Inc.
Package：Bulk

SKU:82f52a90cb5a Category: RF Switches Brand: Radiall USA, Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC RF SWITCH SPDT 3GHZ MODULE
Series：-
Mfr：Radiall USA, Inc.
Package：Bulk
Product Status：Active
RF Type：General Purpose
Topology：-
Circuit：SPDT
Frequency Range：0Hz ~ 3GHz
Isolation：80dB (min)
Insertion Loss：0.15dB (max)
Test Frequency：3GHz
Impedance：50Ohm
Voltage - Supply：24V ~ 30V
Operating Temperature：-40°C ~ 85°C
Mounting Type：-
Package / Case：Module, SMA Connectors
P1dB：-
IIP3：-
Features：-
Supplier Device Package：Module
Grade：-
Qualification：-

Download product information

R570313000

Overview

The Radiall R570313000 is an SPDT coaxial switch from the Ramses series, designed for RF signal routing. It utilizes SMA connectors and supports frequencies up to 3 GHz. The device operates on a 12 Vdc supply with TTL-compatible driver inputs. Key electrical specifications include a characteristic impedance of 50 Ohms, maximum insertion loss of 0.5 dB, and isolation of 60 dB. It features failsafe indicators and suppression diodes, with pin terminals for connection.
