Product Detailed Parameters
- Description：IC RF SWITCH SPDT 18GHZ MODULE
- Series：-
- Mfr：Radiall USA, Inc.
- Package：Bulk
- Product Status：Active
- RF Type：General Purpose
- Topology：-
- Circuit：SPDT
- Frequency Range：0Hz ~ 18GHz
- Isolation：60dB (min)
- Insertion Loss：0.35dB (max)
- Test Frequency：18GHz
- Impedance：50Ohm
- Voltage - Supply：10.2V ~ 13V
- Operating Temperature：-40°C ~ 85°C
- Mounting Type：-
- Package / Case：Module, SMA Connectors
- P1dB：-
- IIP3：-
- Features：-
- Supplier Device Package：Module
- Grade：-
- Qualification：-
Download product information
Overview
The Radiall R570412100 is a Ramses series coaxial switch featuring an SPDT contact configuration and SMA interface. It operates at frequencies up to 18 GHz with a 50 Ohm impedance. The device utilizes a 12 VDC coil voltage and employs solder pin terminals for mounting. Key electrical parameters include a VSWR of 1.4:1, insertion loss of 0.35 dB, and isolation of 60 dB. It supports 10 million cycles and functions within a temperature range of -40 C to +85 C.
Feature Summary
- SPDT switching topology for signal path selection
- SMA connector interface for high-frequency applications
- Failsafe operational mode with indicator capabilities
- Low PIM design optimized for multi-carrier systems
Applications
- Base station antenna distribution systems
- RF test and measurement instrumentation
- Wireless infrastructure signal routing
- Military and aerospace communication equipment
Procurement Notes
Verify current availability directly with the manufacturer or authorized distributors, as lifecycle status may vary. Confirm specific ordering suffixes match required interface and voltage specifications. Request official datasheets for precise mechanical drawings and compliance documentation before integration into final designs.
Selection Notes
Select this component for applications requiring low passive intermodulation performance in dense RF environments. Ensure the 12 VDC control voltage aligns with system power supplies. Verify that the SMA interface and solder pin termination are compatible with the PCB layout and housing constraints.
Part Context
This part belongs to the Ramses family of coaxial switches from Radiall. The series offers various configurations including SPDT and SP4T options with different frequency ranges and connector types. The R570412100 specifically targets high-performance base station applications requiring reliable signal switching with minimal distortion.
Replacement Considerations
Consult official substitution lists for direct equivalents. Cross-reference technical specifications such as frequency range, contact configuration, and interface type when evaluating alternative components.
