R570463100

$308.63

Description：IC RF SWITCH SPDT 18GHZ MODULE
Series：-
Mfr：Radiall USA, Inc.
Package：Bulk

SKU:f74c1ca8150d Category: RF Switches Brand: Radiall USA, Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC RF SWITCH SPDT 18GHZ MODULE
Series：-
Mfr：Radiall USA, Inc.
Package：Bulk
Product Status：Active
RF Type：General Purpose
Topology：-
Circuit：SPDT
Frequency Range：0Hz ~ 18GHz
Isolation：60dB (min)
Insertion Loss：0.35dB (max)
Test Frequency：18GHz
Impedance：50Ohm
Voltage - Supply：24V ~ 30V
Operating Temperature：-40°C ~ 85°C
Mounting Type：-
Package / Case：Module, SMA Connectors
P1dB：-
IIP3：-
Features：-
Supplier Device Package：Module
Grade：-
Qualification：-

Download product information

R570463100

Overview

The R570463100 is a single-pole double-throw (SPDT) coaxial switch from the Ramses series, manufactured by Radiall. It features SMA connectors and operates up to 18 GHz. The device utilizes latching technology with self-cut-off indicators and requires a 28 VDC TTL drive signal. Designed for low PIM applications, it integrates diodes, pins, and terminals for control interface connectivity.

Feature Summary

Low passive intermodulation (PIM) design suitable for sensitive RF environments
Integrated self-cut-off indicator system for state verification
Latching mechanism with 28 VDC TTL control input

Applications

Telecommunications base stations
Test and measurement instrumentation
Radar systems requiring low PIM performance

Procurement Notes

Verify component authenticity through authorized Radiall distributors or direct factory channels. Confirm RoHS compliance status and specific manufacturing lot details upon order confirmation. Ensure technical specifications match application requirements before finalizing procurement transactions.

Selection Notes

Select this model for applications requiring SPDT switching at frequencies up to 18 GHz with low PIM characteristics. Verify that the 28 VDC TTL control voltage aligns with available system power supplies. Consider physical dimensions and panel mount requirements during integration planning.

Part Context

This component belongs to the Ramses series of coaxial switches, designed for high-frequency RF signal routing. The series emphasizes low passive intermodulation performance, making it suitable for modern wireless infrastructure where signal integrity is critical.
