R573432625LP

Overview

The R573432625LP is an SP6T RF switch IC from the Ramses series, manufactured by Radiall USA, Inc. It operates within a frequency range of 0 Hz to 18 GHz and features a nominal supply voltage of 12 V. The component utilizes a D-sub connector interface and includes latching indicators for status monitoring. Designed for general-purpose applications, it supports positive common configurations with auto-reset capabilities.

Feature Summary

• SP6T configuration for general-purpose RF signal routing
• Operational frequency range extending up to 18 GHz
• Integrated latching indicators for state visibility
• Auto-reset functionality with self-cut-off protection

Applications

• General-purpose RF switching systems
• Test and measurement equipment requiring high-frequency signal routing
• Telecommunications infrastructure components

Procurement Notes

Verify current availability directly with Radiall or authorized distributors, as stock levels may vary. Confirm that the specific ordering suffix matches the required pinout and connector type. Ensure environmental compliance documentation is obtained prior to integration into final assemblies.

Selection Notes

Select this component when an SP6T topology is required for frequencies up to 18 GHz. Consider the 12 V nominal supply requirement and D-sub connector interface during system design. Evaluate thermal management needs based on the specific application's power dissipation profile.

Part Context

This part belongs to the Ramses family of coaxial switches, designed for robust performance in demanding RF environments. The series offers various port configurations and control options, with the R573432625LP specifically providing SP6T functionality with integrated indicator feedback for simplified system monitoring.

Replacement Considerations

Consult official Radiall substitution guides for verified alternatives. Cross-reference pinouts and electrical specifications carefully before substituting with other SP6T RF switches.
