R573432805

Description：IC RF SWITCH SP8T 18GHZ
Series：SPnT
Mfr：Radiall USA, Inc.
Package：Bulk

SKU:de8f4dc48ae9 Category: RF Switches Brand: Radiall USA, Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC RF SWITCH SP8T 18GHZ
Series：SPnT
Mfr：Radiall USA, Inc.
Package：Bulk
Product Status：Obsolete
RF Type：General Purpose
Topology：-
Circuit：SP8T
Frequency Range：0Hz ~ 18GHz
Isolation：60dB (min)
Insertion Loss：0.6dB (max)
Test Frequency：18GHz
Impedance：50Ohm
Voltage - Supply：10.2V ~ 13V
Operating Temperature：-40°C ~ 85°C
Mounting Type：-
Package / Case：Module
P1dB：-
IIP3：-
Features：-
Supplier Device Package：-
Grade：-
Qualification：-

Download product information

R573432805

Overview

The R573432805 is an SP8T coaxial switch from the Ramses series, manufactured by Radiall USA, Inc. It utilizes SMA connectors and operates up to a maximum frequency of 18 GHz with a 50 Ohm impedance. The device features latching functionality with indicators and supports 12Vdc input. Terminals are pin-type, and it is supplied in bulk packaging.

Feature Summary

SP8T configuration within the Ramses series
SMA connector interface
Latching mechanism with status indicators
12Vdc operational input

Applications

Cryogenic quantum computing interconnect solutions
Industrial cryogenic applications
RF signal routing systems

Procurement Notes

Verify availability directly with the manufacturer or authorized distributors as stock status may vary. Confirm lead times for standard delivery periods. Ensure compatibility with existing SMA interfaces and 12Vdc control requirements before procurement. Check for specific environmental certifications if required for the target application.

Selection Notes

Select this component for high-frequency applications requiring eight-way signal switching. The Ramses series offers robust performance up to 18 GHz. Consider the latching feature for stable state maintenance without continuous power. Verify that the SMA connector type matches the system design constraints.

Part Context

This part belongs to the Ramses series of coaxial switches designed for demanding environments. It complements other Radiall RF components like attenuators and connectors. The series includes various configurations such as SP6T and SP4T models for different channel requirements.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult official Radiall resources for potential cross-references or updated series replacements.
