R573502610

$1,224.72

Description：IC RF SWITCH SP6T 3GHZ
Series：SPnT
Mfr：Radiall USA, Inc.
Package：Bulk

SKU:3f208b7bec3b Category: RF Switches Brand: Radiall USA, Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC RF SWITCH SP6T 3GHZ
Series：SPnT
Mfr：Radiall USA, Inc.
Package：Bulk
Product Status：Active
RF Type：General Purpose
Topology：-
Circuit：SP6T
Frequency Range：0Hz ~ 3GHz
Isolation：80dB (min)
Insertion Loss：0.2dB (max)
Test Frequency：3GHz
Impedance：50Ohm
Voltage - Supply：10.2V ~ 13V
Operating Temperature：-40°C ~ 85°C
Mounting Type：-
Package / Case：Module
P1dB：-
IIP3：-
Features：-
Supplier Device Package：-
Grade：-
Qualification：-

Download product information

R573502610

Overview

The R573502610 is a general-purpose single-pole six-throw (SP6T) RF switch manufactured by Radiall USA, Inc. Designed for radio frequency applications, this component operates with a characteristic impedance of 50 Ohms and supports frequencies up to 3 GHz. The device functions as an integrated circuit switch, enabling signal routing across multiple paths within RF systems.

Feature Summary

Single-pole six-throw (SP6T) configuration for multi-path signal routing
General-purpose design suitable for various RF switching requirements
Integrated circuit form factor for compact system integration

Applications

RF signal distribution networks
Test and measurement equipment
Telecommunications infrastructure

Procurement Notes

Verify current lifecycle status directly with the manufacturer or authorized distributors, as availability may vary. Confirm technical specifications against the official datasheet prior to procurement to ensure compatibility with specific system requirements.

Selection Notes

Select this component for applications requiring SP6T switching capabilities within the 3 GHz frequency range. Ensure the 50 Ohm impedance matches the system design. Evaluate thermal and power handling limits against the official datasheet specifications before implementation.

Part Context

This part belongs to Radiall's portfolio of RF switches. It serves as a solution for routing radio frequency signals in electronic systems. The SP6T topology allows one input to connect to any of six outputs, providing flexibility in signal path management.

Replacement Considerations

Consult official manufacturer documentation for verified substitute part numbers. Cross-reference pin configurations and electrical parameters carefully when evaluating alternatives to ensure functional equivalence.
